Dashboard Deployment

The MergeWatch dashboard is a Next.js application that provides a web UI for managing reviews, repositories, and settings. It authenticates users with GitHub OAuth and connects to the MergeWatch backend API.

Deployment

Self-Hosted (Docker Compose)
SaaS (AWS Amplify)

In self-hosted mode, the dashboard ships as a second service in your docker-compose.yml alongside the MergeWatch server and Postgres.

Docker Compose configuration

The dashboard service is already included in the default docker-compose.yml. Here is the relevant section:

docker-compose.yml

dashboard:
  image: ghcr.io/santthosh/mergewatch-dashboard:0.1.0
  restart: unless-stopped
  environment:
    DEPLOYMENT_MODE: self-hosted
    DATABASE_URL: postgres://postgres:postgres@db:5432/mergewatch
    NEXTAUTH_URL: ${DASHBOARD_URL:-http://localhost:3001}
    NEXTAUTH_SECRET: ${NEXTAUTH_SECRET}
    GITHUB_CLIENT_ID: ${GITHUB_CLIENT_ID}
    GITHUB_CLIENT_SECRET: ${GITHUB_CLIENT_SECRET}
    PORT: "3001"
  ports:
    - "3001:3001"
  depends_on:
    mergewatch:
      condition: service_healthy

Environment variables

Add these to your .env file:

Variable	Required	Description
`GITHUB_CLIENT_ID`	Yes	OAuth client ID from your GitHub App’s OAuth Credentials section (same App, not a separate OAuth App)
`GITHUB_CLIENT_SECRET`	Yes	OAuth client secret from your GitHub App
`NEXTAUTH_SECRET`	Yes	Random secret for NextAuth session signing. Generate with `openssl rand -base64 32`
`DASHBOARD_URL`	No	Public URL of the dashboard. Docker Compose wires this into `NEXTAUTH_URL`. Defaults to `http://localhost:3001`.

The dashboard reads from the MergeWatch Postgres database directly via DATABASE_URL — there is no HTTP call from the dashboard to the Express server, so no NEXT_PUBLIC_API_URL is required.

Start the dashboard

The dashboard starts automatically with the rest of the stack:

docker compose up -d

Access the dashboard at http://localhost:3001.

Upgrade

docker compose pull dashboard
docker compose up -d dashboard

The SaaS dashboard runs on AWS Amplify with Git-native deploys. Push to main and Amplify builds and deploys automatically.

Why Amplify

Zero server management — Amplify handles builds, CDN, and SSL automatically
Git-native deploys — push to main, Amplify builds and deploys
Environment variable management — secrets stored in Amplify Console, injected at build time
Custom domain — one-click custom domain with ACM certificate provisioning

Prerequisites

Your API Gateway URL from the SaaS stack
Your GitHub App credentials (App ID, Client ID, Client Secret)
An AWS account with Amplify access

Environment variables

Configure these in the Amplify Console under App settings > Environment variables.

Never commit environment variables to your repository. Variables prefixed with NEXT_PUBLIC_ are embedded in the client bundle and visible to users — do not use this prefix for secrets.

Required — GitHub OAuth

Variable	Description	Where to find it
`GITHUB_CLIENT_ID`	GitHub App’s OAuth Client ID	GitHub App settings > OAuth Credentials
`GITHUB_CLIENT_SECRET`	GitHub App’s OAuth Client Secret	GitHub App settings > OAuth Credentials
`NEXTAUTH_SECRET`	Random secret for NextAuth session signing	Generate: `openssl rand -base64 32`
`NEXTAUTH_URL`	Full URL of your deployed dashboard	Your Amplify app URL

Required — SaaS billing wiring

Variable	Description	Where to find it
`DEPLOYMENT_MODE`	Set to `saas` to enable the billing UI	Amplify env var
`BILLING_API_URL`	Base URL of the BillingHandler Lambda	SAM stack output: `BillingUrl`
`BILLING_API_SECRET`	Shared secret for dashboard → BillingHandler auth	SSM: `/mergewatch/{stage}/billing-api-secret`
`GITHUB_APP_ID`	GitHub App ID	GitHub App settings
`GITHUB_APP_SLUG`	GitHub App slug (used to build install URLs)	GitHub App settings

Deployment steps

Connect your repository to Amplify

Open the AWS Amplify Console
Click Create new app > Host web app
Select GitHub as your source provider
Authorize Amplify to access your GitHub account
Select the repository and the main branch
Click Next

Configure build settings

Amplify auto-detects Next.js. Confirm the build spec:

amplify.yml

version: 1
frontend:
  phases:
    preBuild:
      commands:
        - npm ci
    build:
      commands:
        - npm run build
  artifacts:
    baseDirectory: .next
    files:
      - '**/*'
  cache:
    paths:
      - node_modules/**/*

Set environment variables

Add all required environment variables under Advanced settings > Environment variables during setup, or navigate to Amplify Console > Your app > App settings > Environment variables.

Deploy

Click Save and deploy. First deploy takes approximately 3-5 minutes. Subsequent deploys triggered by git push typically take 2-3 minutes.

Set NEXTAUTH_URL

Once deployed, copy your Amplify app URL (e.g. https://main.abc123.amplifyapp.com) and update the NEXTAUTH_URL environment variable. Trigger a redeploy.

Add this URL to your GitHub App’s Callback URLs in GitHub App settings (Settings > Developer settings > GitHub Apps > your app > General > Callback URL).

(Optional) Set a custom domain

In App settings > Domain management, add your custom domain. Amplify provisions an ACM certificate automatically. DNS propagation takes 10-30 minutes.

GitHub authentication

The dashboard uses NextAuth.js with the GitHub provider. The same GitHub App that handles webhooks also authenticates users — there is no separate OAuth app.

GitHub scopes requested

MergeWatch requests the minimum scopes needed:

Scope	Why
`read:user`	Get authenticated user’s profile and username
`user:email`	Display user identity in the dashboard header

The GitHub App installation permissions (not OAuth scopes) handle repository access — the OAuth login is purely for identity, not code access.

Organization support

Org installation — when a GitHub App is installed on an org, any org member with admin rights can access the dashboard for that installation
Access check — the dashboard calls GET /orgs/{org}/members/{username} with role=admin to verify the user is an org admin before showing settings controls
Multiple installations — a single user can have multiple installations (personal + multiple orgs). The dashboard shows all installations and lets them switch between them
No separate org concept — GitHub’s own org membership model is the source of truth for access control

Session model

Sessions are stored as encrypted JWT cookies (default NextAuth behavior). No session database is needed. The JWT contains:

GitHub user ID and username
OAuth access token (for GitHub API calls from the frontend)
Installation IDs the user has access to

Session expiry defaults to 30 days.

Connecting dashboard to backend

The dashboard’s Next.js API routes read from the same data store the webhook pipeline writes to — Postgres in self-hosted mode and DynamoDB in SaaS mode. There is no HTTP call from the dashboard to the Express/Lambda webhook server, so no public API URL environment variable is required. Access control lives in each /api/* route: it validates the NextAuth session, calls the GitHub API with the user’s OAuth token to confirm installation access, then reads/writes the store.

Troubleshooting

Build fails with 'Module not found'

Run npm ci locally and confirm the build passes before pushing. Check that package-lock.json is committed.

Sign-in fails with 'Configuration' error

Blank dashboard after sign-in

GitHub returns 'redirect_uri_mismatch'

Add your dashboard URL to your GitHub App’s Callback URLs in GitHub App settings (Settings > Developer settings > GitHub Apps > your app > General > Callback URL).

User sees wrong installation data

Confirm the GITHUB_APP_ID matches your deployed GitHub App. Mismatches cause installation lookups to return empty results.
